Intersatellite Links

Intersatellite Communications Solutions

The number of satellites on the low Earth orbit (LEO) keeps growing, and their constellations require much wider data pipes to the ground. Operators of communications satellites are under pressure to deliver higher data throughputs at lower latency. Also, Earth observation (EO) satellites collect a tremendous amount of imaging data which needs to be delivered to users with a minimum delay, but the traditional ground link from satellites to Earth stations is discontinuous and may not be available on every orbital turn of the satellite, hence can create significant delays in data delivery.

These issues can be addressed by using intersatellite links (ISL) which provide data communications between satellites – within the same constellation or using other providers of such services. This way data can be relayed by one or more satellites before being delivered to Earth via a ground link. This method can provide a continuous ground contact with a minimum latency, i.e. near real time.

Intersatellite links can be established within the same constellation (i.e. between satellites orbiting the Earth at the same or similar altitude) or via satellites at much higher altitudes, i.e. medium (MEO) or geostationary (GEO) orbits. Also, ISLs can employ RF (L-, Ku or Ka-band) or optical spectrum.

Technologies

Cube Sat Idsr

RF satellite relays

A terminal for RF satellite relays can be considered to be akin to a satcom terminal on board of an aircraft, although satellites fly at much higher speed and much higher altitudes. Also, a satellite relay terminal needs to be space-qualified.

Recently TTP has developed a number of satcom terminals for aeronautical applications, and we are involved in the development of a satellite payload, such as RF ISL terminals.

Our experience in the development of communications systems in L-, Ku-, Ka-band and higher frequencies is very applicable to RF ISL terminals.

An example below illustrates our development of an L-band ISL terminal.

Optical Free

Optical free space communications

Optical spectrum provides new opportunities for satellite communications. With frequencies thousands of times higher than RF waves, visible light can carry orders of magnitude more data while keeping the antenna (lens) aperture relatively small. Also, no license is required to operate in optical spectrum, and such communications are more secure due to high beam directivity. Relevant technologies are rapidly maturing, which enables a broader deployment of free space optical communications (FSOC) in commercial and defence satellite networks.

TTP has an extensive experience in technologies required for the development of FSOC terminals, which includes optics (Tx and Rx), actuation for high-precision beam control, waveforms and modems.

case study

IDRS Terminal

TTP is developing a low-SWaP space-qualified satcom data terminal for LEO micro- and nanosatellites and launch vehicles, which enables a resilient near-real-time ground contact based on the Inter-Satellite Data Relay System (IDRS™) provided by Inmarsat via their GEO satellites.

This RF ISL solution operates in L-band and addresses a wide range of applications: satcom Internet of Things (IoT), Earth Observations (EO), Satellite Tracking, Active Debris Removal (ADR).
